1.7 inch LCD 128x64 Graphic LCD Display | ST7567 | SPI Interface | Graphic Module Display, STN + Yellow-Green Backlight

1.7 inch LCD 128x64 Graphic LCD Display | ST7567 | SPI Interface | Graphic Module Display, STN + Yellow-Green Backlight | With Datasheet

▶ Model: HTM12864C01A-01Y-A5P

▶ Type: Standard COB LCD module
▶ Display pixels: 128x64
▶ Overall dimensions (mm): 52.0x44.2x6.4
▶ VA size (mm): 36.0x23.5
▶ AA size (mm): 33.25x20.45
▶ Viewing angle: 6H
▶ Point spacing (mm): 0.38x0.32
▶ Backlight/brightness: yellow-green light
▶ Pin: 12PIN
▶ Interface mode: SPI
▶ Working temperature: -20~70℃
▶ Supply voltage: 3.3v
▶ Driver chip: ST7567
