2.9-inch 128x64 LCD Graphic LCD Display Module | STN Positive Film | 3.3V | MCU | Arduino | ST7565R

2.9-inch 128x64 LCD Graphic LCD Display Module | STN Positive Film | 3.3V | MCU | Arduino | ST7565R | Gray Background Blue Text

▶ Model: HTM12864-8G-11W-A5P

▶ Type: COG LCD module with plate
▶ Display pixels: 128x64
▶ Overall dimensions (mm): 80x70x11.3
▶ VA size (mm): 65.6x38
▶ AA size (mm): 60.775x32.935
▶ Point spacing (mm): 0.475x0.515
▶ Application: Industrial Control
▶ Viewing angle: 6H
▶ Backlight: white light
▶ Pin: 16PIN
▶ Interface mode: MCU
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20℃~70℃
▶ Power supply voltage: 3.3V
▶ Driver chip: ST7565R

Product Consultation Datasheets Download Demo Code
