1.7"LCD1264 LCD screen/LCM128x64 graphic dot matrix module/blue background with white characters/ST7567/SPI/1.7 inch

1.7"LCD1264 LCD screen/LCM128x64 graphic dot matrix module/blue background with white characters/ST7567/SPI/1.7 inch

▶ Model: HTM12864C-25W-N3S-V06

▶ Type: Standard COB LCD module
▶ Display pixels: 128x64
▶ Overall dimensions (mm): 39.0x40.8x6.2
▶ VA size (mm): 36x23.5
▶ AA size (mm): 33.25x20.45
▶ Point spacing (mm): 0.32x0.26
▶ Application: Industrial Control
▶ Viewing angle: 6H
▶ Backlight/Brightness: White backlight, white text on blue background
▶ Pin: 12PIN
▶ Interface mode: SPI
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -40~70℃
▶ Power supply voltage: 3.3v
▶ Driver chip: ST7567
