TFT-H047A3HDIST4N20 | 4.7-inch IPS TFT LCD | MIPI DSI interface | 720x1280px high-resolution LCD screen | Optional capacitive touch / resistive touch
This 4.7-inch IPS TFT The LCD display features a high resolution of 720x1280 pixels and built-in EMI shielding. This TFT includes a high-brightness LED backlight with a typical brightness rating of 500 nits. Because this LCD has built-in IPS technology, the display features amazing clarity, excellent color reproduction, better image consistency, and high contrast at all viewing angles. The ultra-bright backlight makes the TFT sunlight readable in bright conditions including direct sunlight.
While this transmissive LCD does not include a touchpad, the impressive graphics quality provided by its 2.8V power supply makes it an excellent choice for projects that want high-end visual output without touchscreen functionality. This TFT display is powered by a built-in ST7703 driver IC and is compatible with Raspberry Pi/Android/RK, providing excellent performance and reliability. The driver optimizes the display's functionality, ensuring smooth operation and accurate rendering of images and graphics. This LCD uses an FFC (Flat Flexible Cable) connection method to ensure easy electrical connections. Our monitors are all RoHS compliant and adhere to strict environmental and safety standards.
Customized Ribbon Cables/Flexible Printed Circuits (FPC): Tailor your cables to perfection by adjusting their length, position, and pin arrangements, or adding other connectors. Obtain a precisely designed cable solution to streamline and enhance the safety of your connections |
Touchscreen Add-On Components: Enhance your user experience with capacitive or resistive touchscreen technology. We can adjust the glass thickness or shape of the touchscreen to ensure a perfect fit for your design. |
Interface Customization: Choose from various interface options or consult with our experts to select the options that best suit your project. We can integrate HI,USB, SPI, VGA, and other interfaces into your display to achieve your design goals. |
Cover Glass: Equip your display with custom-cut cover glass to improve durability. Choose from various thicknesses of cover glass and undergo optical bonding to prevent moisture and debris. |
