2.7 inch Graphic LCD 128x64 Module | 128 x 64 Graphic LCD | STN Positive | Yellow-green Backlight

2.7 inch Graphic LCD 128x64 Module | 128 x 64 Graphic LCD | STN Positive | Yellow-green Backlight | SPI Interface

▶ Model: HTM12864-122-11Y-A5P

▶ Type: LCM graphic dot matrix
▶ Display pixels: 128x64
▶ Overall dimensions (mm): 93x70x13.5
▶ VA size (mm): 65.5x38.0
▶ AA size (mm): 60.77x32.93
▶ Application: Instrumentation
▶ Viewing angle: 6H
▶ Pin: 20pin
▶ Interface mode: SPI
▶ Backlight：yellow-green
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Supply voltage: 3.3V
▶ Driver chip: ST7567
