UART/RS232/RS485 Smart Display

Smart Display

The Hot Display EzUI series intelligent LCD display modules, namely: E (easy), z (zero code), and UI (user interface), are distinguished by their user-friendly operation and rich functionality, catering to both simple and complex user requirements. Users can employ the interface development tool software (EzUITool) to design and edit human-machine interfaces, configure controls, set responses, and more. By transferring the resource files generated by the tool software into the EzUILet series modules, one can achieve the desired human-machine interface design without the need for microcontroller or other controller programming. To accommodate users with specific needs, the EzUILet series modules also retain a majority of display control commands, allowing for more flexible control over the module's display.

The EzUILet series is derived from the EzUI series and is considered part of the EzUI family. Compared to the EzUI series, the EzUILet series has streamlined some control attributes and replaced the module's USB device interface with a virtual serial port, altering the method of resource file writing from the original EzUI series. Additionally, the EzUILet series has reduced the capacity of the resource memory to a more reasonable size, enhancing reliability. The non-touch versions within the EzUILet series require the user's MCU to send key messages, which then trigger events within the module's internal GUI system, marking the primary difference from the touch-enabled EzUI series modules. The naming of various controls within the GUI system of the EzUILet series modules continues to follow the nomenclature used in the EzUI series modules.

<12 3 > 1 / 3

1 / 3

TFT Size

TFT Interface

TFT resolution

Touchscreen

Display Type

TFT LCD/TFT module

Compatible systems
