2X16 Character LCD Module Display | DFSTN- with Side White Backlight-Arduino

2X16 Character LCD Module Display | DFSTN- with Side White Backlight-Arduino

▶ Model: HTM1602-9-41W-A5P

▶ Type: Standard COB character LCD module
▶ Display content: 16x2 characters
▶ Overall dimensions (mm): 100.0x38.0x13.0
▶ VA size (mm): 80.0x20.5
▶ AA size (mm): 76.37x16.02
▶ Point spacing mm: 0.83x0.98
▶ Product application: industrial equipment
▶ Viewing angle: 6H
▶ Backlight type: white light
▶ Number of connection PINs: 16PIN
▶ Interface mode: MCU/8bit
▶ Special instructions: Anti-static ESD 8KV
▶ Working temperature: -20~70℃
▶ Power supply voltage: 5.0v
▶ Driver chip: ST7066U
