1.5 inch 128x64 COG LCD | STN(+) yellow-green dot matrix COG | ST7565R | 3.3V

In the trend of embedded devices pursuing miniaturization and efficient integration, this 1.5 inch 128x64 COG LCD display stands out with its breakthrough design concept and becomes an ideal visual solution for space-sensitive applications. Its core is a precise 1.5-inch white background monochrome dot matrix LCD screen, and innovatively uses the advanced COG (Chip on Glass) process. This process directly encapsulates the driver chip on the glass substrate, achieving a breakthrough compression of the module thickness and volume, providing high-density integrated key components for those devices with extremely valuable internal space. At the same time, the FPC with metal pins can be easily assembled and disassembled with the connector, providing a convenient and worry-free way for users with weak welding ability, effectively solving the space problem of the human-computer interaction interface in miniaturized devices.

To ensure wide applicability and convenient development experience, this 1.5 inch 128x64 COG LCD display is equipped with a mature ST7567 controller and optimized interface architecture. This makes it show excellent hardware compatibility, and can seamlessly connect from traditional microcontroller architectures such as classic 8051, PIC, AVR, to modern popular Arduino platforms, various ARM processors, and development boards such as Raspberry Pi. This "plug-and-play" connection feature significantly reduces the development threshold of embedded systems and accelerates the product launch process.

In terms of optical performance, the module adopts an innovative semi-transparent display mode to achieve intelligent adaptation to ambient light conditions. In a dark environment with insufficient light, the built-in yellow-green backlight penetrates the liquid crystal layer, presenting a bright and sharp positive display effect to ensure that the information is clearly visible; while under conditions of sufficient natural light, it automatically switches to the reflective mode, making full use of ambient light to clearly display content while reducing power consumption. This dual-mode collaborative working mechanism ensures that users can obtain a stable and reliable visual experience in all scenarios, from the inside of industrial control cabinets with complex light to outdoor equipment with direct strong light.

To meet the diverse needs of different industries and application scenarios, the manufacturer provides in-depth customization support. Users can choose different display technologies such as STN(±), FSTN(+) or DFSTN(-) according to specific needs, and match them with a variety of appearance combinations, such as blue text on a gray background, black text on a white background, or white text on a black background. What is more worth mentioning is that considering the final installation position of the equipment (such as looking up from the bottom of the console, or looking down from the top of the instrument), users can pre-configure the optimal viewing direction options of 6:00 (bottom viewing angle) or 12:00 (top viewing angle). This refined 1.5 inch 128x64 COG LCD display is designed to ensure that end users can get the most natural and comfortable reading experience regardless of the installation posture, thereby improving the friendliness of human-computer interaction.
