Graphic COG LCD 2.2" 128x64 | STN+Yellow-Green Backlight | SPI | ST7567

Graphic COG LCD 2.2" 128x64 | STN+Yellow-Green Backlight | SPI | ST7567 | Arduino

▶ Model: HTG12864T02A-01Y--SPI-FONT

▶ Type: Graphic COG LCD
▶ Display pixels: 128x64
▶ Overall dimensions (Mm): 53.2x37.8x2.8
▶ Display inches: 2.2"
▶ VA size (mm): 49.2x27.0
▶ AA size (mm): 40.92x24.28
▶ Point spacing (mm): 0.38x0.32
▶ Application: Instrumentation
▶ Viewing angle: 6H
▶ Backlight/brightness: yellow-green light
▶ Pin: FPC-10PIN
▶ Interface mode: SPI
▶ Description: With Chinese, English and Russian text library
▶ Working temperature: -20~70℃
▶ Supply voltage: 3.3V
▶ Driver chip: ST7567
