2 inch 128 x 64 Graphic LCD | For Arduino | White Backlight | 128x64 Graphic LCD Module | ST7567 SPI | STN Negative Display | White Characters on Blue Background
2 inch 128 x 64 Graphic LCD Blue Background with 128x64 monochrome white pixels cob (chip on PCB board) LCD module, ST7567 controller, compact size, high contrast, wide operating temperature, white LED backlight, stn-lcd negative, optional pin header and font chip (contains Chinese characters or ISO8859, ASCII, Unicode, LCM characters), it is a 4-wire serial spi interface.
It can be easily controlled by MCUs such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry Pi. It can be used in any embedded system, industrial equipment, security, medical and handheld devices.
Connector Customization: Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require. |
PCB Modifications: Choose from a variety of changes to the PCB's shape, size, pinout, and component layout to make it perfect for your application. |
Backlight color customization: The module backlight has a variety of combinations to choose from, without backlight or with yellow-green/blue/white/amber/red/RGB backlight options. There are 48 effects. You can click on the customization page for reference. |
Font library customization: Provides a variety of font libraries, including English/Japanese, Western Europe, Eastern Europe, Scandinavian Europe, Cyrillic (Russian), Hebrew/Arabic, etc. |
Cable Customization: Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure. |
