2.0-inch LCD12864 graphic LCD screen/LCM128x64 graphic dot matrix module/RGB red, green and blue backlight/Chinese, English, Russian and Japanese character library

2.0-inch LCD12864 graphic LCD screen/LCM128x64 graphic dot matrix module/RGB red, green and blue backlight/Chinese, English, Russian and Japanese character library

▶ Model: HTM12864-23-35S-A5P

▶ Type: COG LCD module with board
▶ Display pixels: 128x64
▶ Overall dimensions (mm): 54.6x50.0x9.1
▶ VA window size (mm): 45.2x27.0
▶ AA size (mm): 40.93x24.29
▶ Point spacing (mm): 0.38x0.32
▶ Application: stage controller
▶ Viewing angle: 6H
▶ Backlight: red green blue light
▶ Pin: 16PIN
▶ Interface: MCU
▶ Working temperature: -20~70℃
▶ Supply voltage: 3.3V
▶ Driver chip: ST7565
