Product type：Character LCM

Show contents：20*4Character

Outline size(mm) ：98.0*60.0*14.2

Size of View Window(mm)：76.0*25.8

Display size(mm) ：70.4*20.8

Point spacing(mm)：0.6*0.6

Visual angle：6H

Backlight type or brightness：GREEN

Connection PIN Number：16PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：5.0v

CAD Drawings:
