320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
320*240 COG LCD Graphic/HTG320240A
US$26.99
Add to wish list
Quantity
+
Product details
Model : 320*240 COG LCD Graphic/HTG320240A

Product type:COG

Show contents:320*240

Outline size(mm) :107.0*86.0*10.5

Size of View Window(mm):102.2*72.3

Display size(mm) :89.58*67.18

Point spacing(mm):0.28*0.28

Visual angle:6H

Backlight type or brightness:WHITE

Connection PIN Number:FPC-45PIN

Interface mode:SPI

Working temperature:-20~70℃

Power supply voltage:3.3v

Driver chip model:ST75320

CAD Drawings
