Product type：Graphic LCM

Show contents：240*128

Outline size(mm) ：144..0*104.0*14.6

Size of View Window(mm)：114.0*64.0

Display size(mm) ：107.95*57.55

Point spacing(mm)：0.45*0.41

Visual angle：6H

Backlight type or brightness：WHITE

Connection PIN Number：21PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：5.0V

CAD Drawings:
