Product type：COB Character LCM

Show contents：16*4Character

Outline size(mm) ：87.0*60.0*10.4

Size of View Window(mm)：62.0*27.2

Display size(mm) ：56.2*20.8

Point spacing(mm)：0.55*0.55

Visual angle：6H

Backlight type or brightness：WHITE

Connection PIN Number：16PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：5.0v

CAD Drawings:
