Product type：Character LCM

Show contents：16*2Character

Outline size(mm) ：80.0*36.0*13.1

Size of View Window(mm)：64.5*15.8

Display size(mm) ：55.8*10.64

Point spacing(mm)：0.62*0.64

Visual angle：6H

Backlight type or brightness：YG

Connection PIN Number：16PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：5.0v

CAD Drawings:
