Product type：COG

Show contents：128*64

Outline size(mm) ：53.2*37.8*2.8

Size of View Window(mm)：45.2*27.0

Display size(mm) ：40.92*24.28

Point spacing(mm)：0.32*0.38

Visual angle：6H

Backlight type or brightness：WHITE

Connection PIN Number：FPC-28PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：3.3v

Driver chip model：ST7567R

CAD Drawings:
