Product type：COG

Show contents：128*64

Outline size(mm) ：80*54

Size of View Window(mm)：70.7*38.8

Display size(mm) ：66.52*33.24

Point spacing(mm)：0.52*0.48

Visual angle：6H

Backlight type or brightness：WHITE

Connection PIN Number：FPC28PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：3.3v

Driver chip model：ST7565P

CAD Drawings:
