Product type：COG

Show contents：128*32

Outline size(mm) ：63.0*27.5*2.0

Size of View Window(mm)：59.0*17.5

Display size(mm) ：56.033*14.526

Point spacing(mm)：0.438*0.455

Visual angle：6H

Backlight type or brightness：WHITE

Connection PIN Number：FPC-28PIN

Interface mode：MCU/8bit

Working temperature：-20~70℃

Power supply voltage：3.3v

Driver chip model：ST7565R

CAD Drawings:
